Power input voltage: DC +10V to +30V. Host connection: Standard D-Sub 9 pin female connectors. RS-232 interface: Standard D-Sub 9 pin female connector RS-232 signal: TXD, RXD, and GND. RS-422/485 interface: Industrial plug-in screw terminal. RS-485 signal: differential 2 half-duplex wires (DATA+, DATA-). RS-422 signal: differential 4 full-duplex wires. (TX+, RX+, TX- , RX-) Plug-in screw terminal wiring: Accepts AWG #12 ~30 wires. Transmission distance: RS-422/485 up to 4000ft (1200M). Communication speed: from 300bps to 115.2Kbps. Isolation voltage: 3000V DC. Serial data format: Asynchronous data with all common combination of bits, parity, stop. Signal LED: Power on, TX, and RX. Power supply: Screw terminal, or external DC adapter. Power consumption: 1.2 watt. Operating Temperature:-10 to 50?. Storage Temperature: -20 to 70?. Humidity: 10-90% Non-condensing. Dimension: 151mm X 75mm X 26mm Weight: 375g.
Producent: Trycom Technology Co.,Ltd
-
- Ilość sztukCeny netto [PLN]
Ceny brutto [PLN] - 1+0.0000 0.0000
- Ilość sztukCeny netto [PLN]
Power input voltage: DC +10V to +30V. Host connection: 2 standard D-Sub 9 pin female connectors. RS-232 interface: Standard D-Sub 9 pin female connector. RS-232 signal: TXD, RXD, GND. RS-422/485 interface: Industrial plug-in screw terminal. RS-485 signal: Differential 2 half-duplex wires (D+, D-). RS-422 signal: Differential 4 full-duplex wires. (TX+, RX+, TX-, RX-) . Communication speed: Form 300bps to 115.2Kbps auto detecting. RS422/485 line protection: Against surge, short circuit, voltage peak. Distance: Up to 4000ft (1200M). Isolation voltage: 3000V DC. Plug-in screw terminal wiring: Accepts AWG #12 ~ 30 wires. Signal LED: Power on, TXA, RXA, TXB, RXB. Power supply: Screw terminal, or external DC adapter. Power consumption: 1.3W. Operating environment:-10 to 50? . Storage temperature: -20 to 70? . Humidity: 10-90% Non-condensing. Dimension: 151mm X 75mm X 26mm . Weight: 375g .
Producent: Trycom Technology Co.,Ltd
-
- Ilość sztukCeny netto [PLN]
Ceny brutto [PLN] - 1+0.0000 0.0000
